CNC Busbar Bending Machine
Product Description
The CNC busbar bending machine is mainly for bending copper and aluminium busbars with high speed and high bending precision.The machine is composed of mainframe,gauge block,servo power system and control panel board.The machine is sero drive automatic bending equipment.Through the moving of the X-axis and Y-axis,the machine can complete vertical bending,horizontal bending and other functions eith the right bending dies.
The machine uses AC sero drive,smoothly operated,no pollution,low noise,high bending precision.It consumes only teens watts in standby mode.The bending machine is widely used in high and low voltage switchgear,electrical transformer,substation cabinet and busway industries.
Detailed Pictures
Main Features of cnc busbar bending machine:
1.The machine adopts closed type bending structure,it not only has good performance of closed bending and has convenience of open bending.
2.X-axis and Y-axis adopts precise linear guids to guarantee the consistency of the width of the processing angle.
3.The machine has angle error compensation function,the bending precision can reach 0.2mm.
4.When processing vertical bending,the die has automatic function of clamping and releasing so as too guarantee the plateness of machining plane and reduce the injury of curved arc.
Detailed Images
| Item | Unit | CNC-50Z | CNC-80Z |
| Nominal force | kn | 350 | 500 |
| Max size of bending | mm | 12*160 | 16*250 |
| Max stroke of X-axis | mm | 1600/2000 | 1600/2000 |
| Precision deviation of X-axis | mm | 0.10/1000 | 0.10/1000 |
| Bending precision | degree |
±0.1°
|
±0.1°
|
| Max.long of hydraulic cylinder | mm | 220 | 220 |
| Outside dimension | mm | 4200*2500*1820 | 4600*2700*1820 |
| Net weight | kg | 2600 | 3200 |
Samples of cnc busbar bending machine:
Company Information
Jinan Jingpeng CNC machinery Co.,Ltd is a company, specializing in the development production , selling of electrical and CNC metalplate machines.
We are professional manufacturer for busbar processing machine in China for more than ten years. Our busbar processing machine are approved by ISO & CE certificate, the machine quality is highly respected among customers in North America, Europe and most Asia countries.
Advantages
1. We are factory. we can do OEM as per clients request.
2. Our PLC are from Siemens. Our thermal relays, AC contactors, circuit breakers are from Schneider.
3. We have strong after-sales services team and professional technicians who can gurantee professional guidance after sales.
4. With Certification of CE&ISO 9001 .
Packaging & Shipping
FAQ
1. What is your payment terms:
40% TT as deposit, balance be paid when goods are ready for loading before shipment.
2. What is your delivery time?
Usually within 7-20 days after the deposit.
3. What is your power supply?
We will adjust according to your countries power supply. No problem.
4. What is your Min order quantity?
One set. Our customers can be end users, retailers and wholesalers.
5. If I buy your CNC busbar processing machine, will you offer me PLC backup?
Yes, we will.
6. Are all the Labels and instuctions of the machine in English?
Yes. the labels on the machine and the manuel books are all made in english version.
7. Besides this machine, do you have any other options for me?
We have dozens of options for you:
CNC busbar machine; Non- CNC busbar machine, combined busbar machine,busbar cutting tools, busbar bending tools, busbar punching tools.hydraulic pumps, hand pumps etc.
Any questions, please don't hesitate to contact me.
